Frame
Alpha Platinum Aluminium, tapered head tube, internal routing, BSA 73, hidden rack and kickstand mounts, UDH, Boost148, 12 mm thru axle
Fork
RockShox Recon Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42 mm offset, Boost110, 15 mm Maxle Stealth, 120 mm travel
Front hub
Shimano TC500 alloy, CentreLock, 110x15 mm thru axle
Rear hub
Shimano TC500-HG
Rear skewer
Bontrager Switch thru axle, removable lever
Rim
Bontrager Kovee, double-wall, Tubeless-Ready, 28-hole, 23 mm width, Presta valve
Spokes
14 g stainless steel
Tyre
Maxxis Rekon Race, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40"
Tyre sealant
Bontrager TLR, 180 ml
Rim strip
Bontrager TLR
Max tyre size
Frame: 29x2.40"
Shifter
SRAM Eagle 70, 12-speed
Rear derailleur
SRAM Eagle 70, T-Type
Crank
Sram Eagle 70, T-Type, DUB, 32T, 55 mm chainline, 170 mm length
Bottom bracket
SRAM DUB MTB Wide, 73 mm, BSA threaded
Cassette
SRAM Eagle XS-1270, T-Type, 10-52, 12-speed
Chain
SRAM Eagle 70, T-Type, 12-speed
Pedals
VP-536 nylon platform
Saddle
Verse Short, chromoly rails, 145 mm width
Seatpost
Bontrager Line Dropper, 100-170 mm travel, internal routing, 31.6 mm diameter
Handlebar
Bontrager Comp/Rhythm Comp, alloy, 31.8 mm, 5-15 mm rise, 720-750 mm width
Grips
Trek Line Comp, lock-on
Stem
Bontrager Comp/Elite, 31.8 mm, Blendr compatible, 7-degree, 50-80 mm length
Headset
Semi-integrated, sealed cartridge bearing, alloy cups, 1-1/8" top, 1.5" bottom
Brakes
Shimano hydraulic disc, MT4100 lever, MT410 calliper
Brake rotors
Shimano RT54, centerlock, 160-180 mm
Weight
13.73 kg (Size M)
Weight limit
136 kg
