COLOUR | Gloss flame red | CASSETTE | SRAM XG-1275, 10-52T, XD Driver |
---|
FRAME | 6061 alloy, hydroformed T6 aluminium, multi-butted, tapered head tube, internal cable routing and custom Whyte dropouts | CHAIN | SRAM GX Eagle, Power Lock |
---|
FORK | Whyte straight bladed 6061 alloy, alloy tapered steerer, internal cable routing, 12mm thru-axle, flat mount with mudguard and mounting bosses | CRANKSET | SRAM Apex D1, DUB Wide, 170mm, 40t chainring |
---|
REAR SHOCK | N/A | BOTTOM BRACKET | SRAM DUB BSA 68/73mm Road |
---|
HEADSET | No. 69 SRS, 1-1/8in upper and 1.5in lower with sealed cartridge bearings and front entry for cables | SEATPOST | Trans-X YSP38 dropper post, 27.2mm, Rocker remote, size specific drop (sizes XS and S: 70mm travel; sizes M and L: 90mm travel; size XL: 110mm travel). |
---|
REAR HUB | Alloy, double sealed cartridge bearings, 12mm x 142mm thru axle, Center Lock, 32 hole | SADDLE | Whyte Custom |
---|
FRONT HUB | Alloy, double sealed cartridge bearings, 12mm x 100mm thru axle, Center Lock, 32 hole | HANDLEBAR | Controltech, 6061 alloy, 70mm reach, 115mm drop, 10mm rise, 16° flare, 31.8mm x 400mm wide (size XS), 420mm (size S), 440mm (size M), 460mm (size L+XL) |
---|
SPOKES | 2.0mm, PG, black stainless, brass nipples | STEM | Whyte Alloy, +-7° rise, 60mm length (XS, S), 70mm (M, L, XL) |
---|
RIMS | WTB ST i30 rims, 30mm internal width, tubeless ready, 32 hole | GRIPS | Whyte anti-slip, ‘cross bar tape |
---|
TYRE | Maxxis Ravager Tanwall 700 x 50c, EXO 60TPI, folding bead | BRAKES FRONT | SRAM Apex D1, Flat Mount, internal routing, 180mm rotor |
---|
SHIFT LEVERS | SRAM Apex D1, 12 Speed | BRAKES REAR | SRAM Apex D1, Flat Mount, internal routing, 160mm rotor |
---|
FRONT MECH | N/A | BRAKE LEVERS | SRAM Apex D1 |
---|
REAR MECH | SRAM Apex Eagle, 10-52t, 12 Speed | PEDALS | Fibre reinforced composite platform |
---|
